Property Planning for MAB

Sector: Property consulting 

Location: Melbourne, Victoria

Client: MAB Corporation

Services: Aerial photography, Photogrammetry

Completion date: April 2024

Data: Digital Terrain Model, Digital Surface Model, 3D visualisations, Point cloud, Orthophoto mosaic

Property Orthophoto Mosaic part
Property Orthophoto Mosaic part

Landair Surveys provided updated feature and elevation data for a 780-hectare industrial and commercial development site southwest of Melbourne. The survey supported drainage and earthworks strategies by delivering photogrammetrically derived elevation data – verified against ground-surveyed checkpoints – to ensure accuracy.

 Key deliverables included a Digital Terrain Model (DTM), which represents bare earth for drainage design, flood modelling and earthworks planning – as well as a Digital Surface Model (DSM), which incorporates above-ground features for line-of-sight analysis and 3D visualisations. Landair effectively managed challenges, such as obtaining air traffic control clearance in restricted areas and extensive vegetation removal from the DSM, to produce high-quality outputs for future site development.

Services

3D laser scanning. Aerial photography (at 5 cm Ground Sample Distance) and photogrammetry

Key outcomes

  • DSM (5 m grid and 0.5 m grid) in TIFF format
  • DTM (1 m grid) in LAS format
  • Point cloud (0.5 m, classified and unclassified) in LAS format
  • Orthophoto mosaic in TIFF, JPG and ECW formats
